Specifications
Product Classification
| Product Type | SureFlex® Premium, static PIM |
| Product Series | LDF4-50A |
General Specifications
| Body Style, Connector A | Straight |
| Body Style, Connector B | Straight |
| Interface, Connector A | 7-16 DIN Male |
| Interface, Connector B | 7-16 DIN Male |
| Specification Sheet Revision Level | B |
Dimensions
| Length | 2 m | 6.562 ft |
| Nominal Size | 1/2 in |
Electrical Specifications
| 3rd Order IMD Static | -116 dBm |
| 3rd Order IMD Static Test Method | Two +43 dBm carriers |
| DTF, Connector A | -34 dB |
| DTF, Connector B | -34 dB |
Return Loss/VSWR
| Frequency Band | VSWR | Return Loss (dB) |
| 698–960 MHz | 1.06 | 30.72 |
| 1700–2200 MHz | 1.06 | 30.72 |
| 2200–2700 MHz | 1.11 | 26.00 |
